Ascher Racing Artura Sport

THE ULTIMATE TOOL FOR YOUR SUCCESS – CRAFTED WITH ORIGINAL McLAREN ARTURA GT4 PARTS, USING THE SAME ERGONOMICS AND 300MM DIAMETER AS THE MOTORSPORTS WHEEL.

With unprecedented realism, exceptional precision and unmatched quality, the McLaren Esports wheels are redefining what‘s possible in the world of sim racing.

AVAILABLE AS SC AND USB VERSION TO GUARANTEE ULTIMATE COMPATIBILITY.

USB (UNIVERSAL)

• Fanatec
• Asetek
• Simagic
• MOZA
• VRS
• OSW
• Leo Bodnar
• Accuforce
• Logitech
• U.v.m

SC (WIRELESS)

• Simucube 2 Sport, Pro, Ultimate
• Simucube 3 Sport*, Pro*
• Any wheelbase + Simucube Link Hub

• Based on the official McLaren Artura GT4 wheel and uses identical components
• Platform independent USB or Simucube Wireless Wheel™
• Magnetic and silenced single paddle shifters
• Closed design with ergonomic rubber grips for maximum safety, stiffness, and grip
• 14 x RGB illuminated high-quality automotive push buttons with individually adjustable coloring and tactile feedback
• 2 x multifunctional 7-way joysticks
• Official SimHub integration
• SC: Static lighting; brightness and color profiles can be controlled via the steering wheel
• USB: Animated, telemetry-supported lighting
• Upgradeable range of functions (double shifter, clutch paddles)
• 300 mm wheel diameter
• 6 x 70 mm hole pattern

14X RGB PUSH BUTTONS

High-quality illuminated automotive push buttons with tactile feedback that always give you noticeable feedback, with every press. Illuminable with up to 16 million colors and fitted with easily interchangeable and laser-etched button caps.

2x 7-WAY JOYSTICKS

The two joysticks are perfect for navigating through menus or function displays in your simulation. They also have a pressure point and you can use them for brake balance.

PROTECTIVE BUTTONGUARDS

To protect you from operating errors, all buttons are equipped with button guards. This prevents you from accidentally switching to the menu or cancelling your record lap.

DIFFERENCES BETWEEN SC & USB VERSIONS

Customizable RGB Illumination

USB:

• Colors, brightnesses, light effects and animations can be individually adjusted via SimHub
• Support of telemetry-supported light effects
• Support of individual light animations

SC:

• Colors, brightnesses, and color profiles can be changed via button shortcut directly on the wheel and individually adjusted via SimHub
• Freely Configurable Button Mapping

USB:

• Freely configurable button mapping via Ascher Racing Control Center possible
• Free configuration of thumb encoders & rotaries via Control Center possible
• E.g., enables barrier-free switching to other steering wheels, or modifying of buttons and encoders, as well as behavior changes of rotaries (permanent, pulsed, encoder, etc.)

Adjustable Non-Linear Clutch Curves

USB:

• Various predefined non-linear clutch curves with progressive/degressive/s curves selectable
• Individual definition of clutch curves possible via Control Center
• Accurate dead zone adjustment possible
• Separate adjustment and setting of left and right clutch possible

Adjustable Encoder Pulse Width

USB:

• Encoder pulse width adjustable via Ascher Racing Control Center
• Defines how long inputs, e.g., buttons or rotaries are triggered per action
• Precise adjustment in milliseconds: range from 10ms to 200ms

Various Quick Settings Available Without Software Use

USB:

• Reset to factory (default) settings via button shortcut possible (also possible via Control Center)
• Clutch bite point calibration in 0.1% & 1.0% steps (also possible via Control Center)
• Selection of the analog input mode (e.g., for clutches, also possible via Control Center)
• Quick recalibration of the analog axes via button shortcut possible

SC:

• Adjustment of RGB illumination via button shortcut (mode can be accessed via switch on the back of the wheel)
• Rotary input mode can be changed via switches on the back of the wheel (12-pos, rotary, shift)
• Clutch bite point calibration in 0.1% & 1.0% steps via button shortcut

Power Supply & Consumption

USB:

• Power Supply via coiled USB cable or via internal USB-C connection
• No additional power injection necessary, due to low power consumption within USB2.0 specification
• Flawless Asetek QR integration (no visible adapter cable, within power spec, seamless switch between coiled cable and Asetek connection possible)

SC:

• Rechargeable lithium battery
• Low power consumption with at least 800h runtime with lights turned off approx. 30h with lights turned on
• Built-in “safe” mode: wheel will give warning to shut down illumination in case of low battery voltage for additional runtime (approx. 33 hours)

• 300mm diameter
• 6 x 70 mm bolt pattern
• Robust, shielded coiled cable with industrial Binder M16 connector (USB version only)
• Coiled cable connector length approx. 64mm (USB version only)
• Spacer may be required to create sufficient clearance to the wheelbase
• Quick release not included except chosen at check-out
• Mass: 1300g
